DAB e.SYBOX Twin Kit Electronic Pressurisation Set | 2 x 1.1kW
DAB e.SYBOX Twin Kit Electronic Pressurisation Set | 2 x 1.1kW
Couldn't load pickup availability
Premium Twin-Pump Constant Pressure System for Larger Homes and Residential Buildings
The DAB e.SYBOX Twin Kit Electronic Pressurisation Set is a high-performance twin booster system designed for larger domestic, residential and light commercial clean-water pressure applications. The kit combines two DAB e.SYBOX inverter booster units with the e.SYTWIN connection base to create a compact, intelligent twin-pump pressurisation system.
This is a premium solution for customers who need more capacity, redundancy and pressure comfort than a single booster pump can provide. Instead of using a basic fixed-speed pump set, the e.SYBOX Twin Kit uses inverter technology to adjust pump performance according to water demand, helping maintain constant pressure while improving efficiency and system comfort.
Quote-Led Product: Confirm Sizing Before Ordering
This is a high-value technical pressurisation set. Correct selection depends on the number of users, bathrooms, floors, pipe distance, storage tank setup, required pressure and simultaneous water demand.
For best results, contact Zisabo before ordering so we can confirm whether the e.SYBOX Twin Kit is the correct system for your property or project.
Best For
- Larger homes requiring stronger constant water pressure
- Residential buildings and small apartment blocks
- Guesthouses, lodges and small commercial properties
- Tank-to-building pressure boosting
- Rainwater reuse and clean-water pressure systems
- Properties with higher simultaneous water demand
- Projects where pump redundancy and premium system reliability matter
Key Specifications
| Brand | DAB |
| Model | e.SYBOX Twin Kit |
| DAB Code | 60175723 |
| System Type | Twin electronic pressurisation set |
| Kit Includes | 2 x e.SYBOX units + 1 x e.SYTWIN connection base |
| Control Type | Inverter / variable frequency drive constant-pressure control |
| Power Supply | 1 x 220–240V, 50–60Hz |
| Max Flow | Up to 14.4m³/h / 240L/min |
| Max Head | Up to 65m |
| Connection Size | 1¼” suction and delivery fittings |
| Maximum Suction Capacity | Self-priming up to 8m, installation dependent |
| Maximum Operating Pressure | 8 bar |
| Protection Rating | IPX4 |
| Insulation Class | Class F |
| Approx. Weight | 66kg |
| Water Type | Clean water only, free from solids and abrasive particles |
Why Choose a Twin e.SYBOX System?
A twin system provides more capacity than a single booster and can better support properties with higher simultaneous water demand. The two e.SYBOX units work together to deliver pressure according to system demand, while inverter control helps maintain constant pressure and improve energy efficiency.
This makes the e.SYBOX Twin Kit ideal for premium residential and light commercial projects where comfort, performance and reliability are important.
Premium Benefits
- Twin-pump capacity: higher combined flow than a single e.SYBOX unit
- Constant pressure: inverter control adjusts pump speed to match demand
- System redundancy: two-pump setup provides better support for demanding installations
- Compact footprint: e.SYTWIN creates a neater, smaller installation than many traditional twin booster sets
- Quiet operation: water-cooled motors, sound-absorbing housing and anti-vibration feet reduce noise
- Integrated controls: pressure sensors, flow sensors, LCD displays and expansion vessels are built into the e.SYBOX units
- No traditional external pressure tank required: each e.SYBOX includes an integrated expansion vessel
- Installer-friendly: designed as an integrated DAB twin pressurisation solution
Recommended Applications
- Large homes with multiple bathrooms
- Residential complexes and small apartment blocks
- Guesthouses and lodges
- Small commercial buildings
- High-demand tank-to-building pressure systems
- Rainwater reuse systems
- Garden and irrigation systems requiring premium pressure control
Not Suitable For
- Dirty water, grey water, sewage or sludge
- Water containing sand, grit or abrasive particles
- Deep borehole pumping
- Large engineered commercial systems without technical sizing
- Industrial applications requiring a custom-engineered booster set
- Outdoor exposure without suitable protection and correct installation
e.SYBOX Twin Kit vs Single e.SYBOX
| Feature | Single e.SYBOX | e.SYBOX Twin Kit |
|---|---|---|
| System configuration | One integrated booster unit | Two e.SYBOX units with e.SYTWIN base |
| Max flow | Up to 7.2m³/h / 120L/min | Up to 14.4m³/h / 240L/min |
| Best for | Larger homes or premium domestic use | High-demand homes, residential buildings and light commercial projects |
| Redundancy | Single pump system | Two-pump system for better demand support |
| Buying route | Can often be selected for standard homes | Best confirmed with Zisabo before purchase |
Sizing Information We Need
For accurate recommendation, send us:
- Number of bathrooms or units supplied
- Number of storeys
- Water source: tank, municipal, rainwater or other clean-water source
- Estimated simultaneous water demand
- Pipe distance and pipe size
- Required pressure at outlets
- Whether irrigation or garden watering is included
- Project location and installation deadline
WhatsApp Zisabo for sizing support: 083 349 8864
Important Installation Guidance
The e.SYBOX Twin Kit should be installed by a competent installer. Correct performance depends on water source, suction conditions, pipe sizing, system pressure settings, pre-filtration where required and correct commissioning.
The kit components are supplied disassembled and should be assembled and commissioned correctly on site.
What’s Included
- 2 x DAB e.SYBOX electronic pressure booster units
- 1 x DAB e.SYTWIN connection base
- Integrated inverter control in each e.SYBOX unit
- Integrated pressure and flow sensors
- Integrated expansion vessel in each e.SYBOX unit
- LCD display and electronic pressure control
- Twin-pump electronic pressurisation configuration
Frequently Asked Questions
Should I buy the e.SYBOX Twin Kit or a single e.SYBOX?
The single e.SYBOX is suitable for many larger domestic installations. The Twin Kit is better where higher simultaneous demand, building supply, project redundancy or stronger total flow capacity is required.
Does the Twin Kit provide constant pressure?
Yes. Each e.SYBOX uses inverter control to adjust pump speed according to demand, helping maintain constant pressure across the system.
Is this suitable for apartment buildings?
It can be suitable for some residential building applications, but sizing must be confirmed based on number of units, storeys, bathrooms and simultaneous demand.
Does it need a separate pressure tank?
Each e.SYBOX includes an integrated expansion vessel, so a traditional external pressure tank is not normally required for standard e.SYBOX operation.
Can it handle dirty water?
No. The system is designed for clean water only and should not be used with sand, sludge, grey water, sewage or abrasive liquids.
Is this a plug-and-play DIY product?
No. This is a high-value technical pressurisation set. Professional installation and commissioning are strongly recommended.
Request Sizing Support Before You Buy
This is a premium technical system. For the best result, send Zisabo your building layout, number of bathrooms/units, water source and pressure requirement before ordering. We’ll help confirm whether the e.SYBOX Twin Kit is the correct solution for your project.
Guarantees
Guarantees
Dab-backed 24 month warranty
Materials
Materials
Shipping
Shipping
2 - 3 Business Days
Additional Information
Additional Information
• Operating range: Capacity up to 14,4 m3/h; head up to 65 m.
• Protection class IPX4.
• Insulation class F.
• Pumped Liquid clean, free of solids and abrasives, not viscous, not aggressive, not crystallised and chemically neutral.
• Horse Power: 2 x 2.1
• Maximum temperature of liquid 40°C.
• Maximum ambient temperature 50°C.
• Maximum suction capacity Self-priming to 8 metres.
• Maximum operating pressure 8 bar (800 kPa).
