DC Ammeter 72 x 72mm Panel Meter – 5A to 200A, 50mV Shunt Operated | MCE CP72-A

The MCE CP72 is a 72 x 72mm moving coil DC ammeter for panel mounting. It is designed to be used with an external 50mV shunt and displays DC current in ranges from 5A to 200A. It suits electricians, panel builders and maintenance teams working on DC supplies, battery chargers and DC control panels.

• Application: DC current indication on panels
• Ranges: 5A, 10A, 20A, 30A, 40A, 50A, 100A, 150A and 200A
• Input: 50mV DC, shunt operated
• Size: 72 x 72mm panel meter
• Please note: Shunt is not included

Key Features

• Moving coil movement for DC measurement
• Nine current ranges to match the shunt fitted
• Standard 72 x 72mm panel cut-out

Typical Applications

• Battery charger and DC supply panels
• DC control panels
• Solar and battery systems with external shunts
• Industrial and plant DC circuits

Technical Specifications

What’s Included

• 1 x MCE CP72 DC ammeter (selected range)

Please note: The shunt, installation fittings, electrical protection, cables, brackets or accessories are not included unless specifically listed above.

Installation & Compatibility Notes

• Choose the range that matches the 50mV shunt you will use (for example a 100A/50mV shunt needs the 100A meter).
• Confirm the 72 x 72mm panel cut-out before ordering.
• Observe DC polarity when connecting.
• Installation should be carried out by a suitably qualified person.

Warranty & Support

This product is supplied with the applicable manufacturer or supplier warranty, subject to correct installation, correct application, and warranty terms. Zisabo supplies quality plumbing, pump, filtration and electrical products with practical support to help customers choose the correct item for their application.

Need help choosing? If you are unsure whether this product is suitable, contact Zisabo with your DC current, shunt rating and panel cut-out size, and we will assist where possible.
