Distance Control Unit, 2 Pump

The Avanti 2 Pump Distance Control Unit (DCU/2) is a remote float switch relay that controls two pumps operating at different levels, using the same low-voltage float signal principle as the standard single-pump DCU. It is designed for duty/standby pump systems and dual-level control in sumps, dams and tanks, and suits contractors, installers and farmers who need reliable multi-float pump sequencing over long distances.

• Application: Suitable for 2-pump duty/standby or dual-level water control in sumps, dams and tanks
• Key specification: 3 float switch (24V DC), 4-wire control with 2 independent relay outputs
• Distance: Long-distance float wiring using low-voltage 24V DC float circuit
• Supply voltage: Available in 220V AC or 400V AC
• Indication: Power, Relay 1 and Relay 2 LED indicators

Key Features

• Controls 2 pumps independently from 3 float switches — 1 stop float and 2 separate start floats
• Built for "Duty Pump" and "Standby Pump" applications where pumps need to alternate or back each other up
• Can also run 1 pump plus a separate alarm output, using Relay 1 for the pump and Relay 2 for the alarm
• Low-voltage (24V DC) float circuit for safer long-distance wiring
• Clear LED indication for power and both relay states

Typical Applications

• Duty/standby pump systems in sumps and pump stations
• Dual-level dam and reservoir water control
• Tank level control with pump plus alarm output
• Farm and commercial water supply systems with 2 pumps
• Borehole or tank systems needing automatic pump alternation

Technical Specifications

What's Included

• 1 x Avanti 2 Pump Distance Control Unit (Model DCU/2+STR)

Please note: Float switches, control cable, enclosures, electrical protection and installation accessories are not included unless specifically listed above.

Installation & Compatibility Notes

• Confirm your supply voltage (220V AC or 400V AC) before ordering — this determines whether you need the A-DCU/2-M or A-DCU/2-Q variant.
• This unit requires 3 float switches wired as 1 stop float plus 2 separate start floats (4-wire control) — plan your float layout accordingly.
• Never interconnect the 24V float outputs of a DCU/2 and a separate DCU on the same system — this must be avoided at all times per the manufacturer.
• If using 1 pump plus an alarm, a separate dedicated float must be used for the alarm float input.
• Installation should be carried out by a suitably qualified electrician.

Warranty & Support

This product is supplied with the applicable manufacturer or supplier warranty, subject to correct installation, correct application, and warranty terms.

Need help choosing? If you are unsure whether this product is suitable for your system, contact Zisabo with your application details, number of pumps, float layout and supply voltage, and we will assist where possible.
