HURRICANE DC Brushless Surface Solar Pump

The Solar Pal PV HURRICANE is a DC brushless surface solar pump designed to boost water pressure and flow directly from a solar array, without needing mains AC power or a separate inverter. It suits homeowners, farmers and off-grid or load-shedding-affected properties needing a self-contained solar booster pump for tanks, boreholes feeding a tank, or general water transfer.

• Application: Suitable for solar-powered pressure boosting and water transfer
• Key specification: DC brushless surface pump, 280W-750W depending on model
• Outlet size: 1" (HURRICANE-30) or 1"x1" (HURRICANE-50/65)
• Solar panels: Sold separately — HURRICANE-30 needs 1 x 330W panel, HURRICANE-50 needs 2 x 330W panels, HURRICANE-65 needs 3 x 330W panels
• Installation: Supplied complete with an installation pack, 1 x float switch and DC controller

Key Features

• Brushless DC motor runs directly from solar panels through the included DC controller — no mains AC power or separate inverter needed
• Surface-mounted booster pump suitable for pressure boosting and general water transfer applications — must be primed before use (not self-priming)
• Three power options (280W, 550W, 750W) to match different flow and head requirements
• Includes an installation pack and float switch (dry-run/tank-full protection) as standard
• Compact surface-mount design, easy to install near a tank or water source

Typical Applications

• Off-grid or load-shedding-resilient household water pressure boosting
• Tank-to-house water transfer
• Farm and garden irrigation water supply
• General surface water transfer from tanks or reservoirs

Technical Specifications

What's Included

• 1 x HURRICANE solar surface pump (model per variant selected)
• 1 x DC controller
• 1 x installation pack
• 1 x float switch

Please note: Solar panels, a weatherproof DC isolator, and mounting/wiring accessories beyond the installation pack are not included unless specifically listed above. A weatherproof DC isolator is required to isolate the panels for maintenance — refer to the ODD16 to 32D/E2/E4/E22 range for selection according to your application, or contact Zisabo for guidance.

Installation & Compatibility Notes

• Confirm which model you need based on your required head and flow — HURRICANE-30 for lower head, HURRICANE-65 for the highest head in this range.
• Size your solar panel array to the optimum input voltage range and minimum power shown in the spec table — panels are sold separately.
• This pump must be primed before first use — it is not self-priming.
• A weatherproof DC isolator must be fitted between the panels and controller for safe maintenance isolation.
• Installation should be carried out by a suitably qualified installer.

Warranty & Support

This product is supplied with the applicable manufacturer or supplier warranty, subject to correct installation, correct application, and warranty terms.

Need help choosing? If you are unsure whether this product is suitable for your system, contact Zisabo with your required flow, head and available solar panel setup, and we will assist where possible.
