Maximum Demand Ammeter MDI 96 x 96mm CT Operated, 3 Needle – 100/5A to 400/5A | MCE MDI-96-SP

The MCE MDI-96-SP is a 96 x 96mm CT operated maximum demand ammeter with a 15 minute demand period and 3 needles including an instantaneous needle. It shows present load current, holds the highest demand reached and tracks instantaneous current, so it suits electricians, panel builders and facility managers monitoring peak load. It is supplied in 7 ratios from 100/5A to 400/5A.

• Application: Current and maximum demand indication with a 5A secondary CT
• Size: 96 x 96mm panel meter
• Demand period: 15 minutes, 3 needle with instantaneous
• Ratios: 100/5A to 400/5A

Key Features

• Records peak demand over a 15 minute period
• Three-needle display with instantaneous reading
• Large 96 x 96mm face

Typical Applications

• Main distribution boards and incomers
• Load and peak demand monitoring
• Generator and supply sizing checks
• Commercial and industrial installations

Technical Specifications

What’s Included

• 1 x MCE MDI-96-SP maximum demand ammeter (selected ratio)

Please note: The current transformer, installation fittings, electrical protection, cables, brackets or accessories are not included unless specifically listed above.

Installation & Compatibility Notes

• The meter ratio must match the ratio of the current transformer it is connected to.
• Confirm the 96 x 96mm panel cut-out before ordering.
• Never open-circuit a CT secondary while the primary is energised.
• Installation should be carried out by a suitably qualified person.

Warranty & Support

This product is supplied with the applicable manufacturer or supplier warranty, subject to correct installation, correct application, and warranty terms. Zisabo supplies quality plumbing, pump, filtration and electrical products with practical support to help customers choose the correct item for their application.

Need help choosing? If you are unsure whether this product is suitable, contact Zisabo with your CT ratio and panel cut-out size, and we will assist where possible.
