MCE IP44 Industrial CEE Coupler – 16A & 32A | 3P, 4P & 5P

MCE IP44-rated industrial CEE couplers (female connectors) for use with matching CEE plug tops in industrial power distribution systems. Available in 16A and 32A ratings with 3-pin (2P+E / 230V single phase), 4-pin (3P+E / 380V three phase), and 5-pin (3P+N+E / 380V three phase with neutral) configurations. Colour-coded to IEC 60309 standard: blue for 230V single-phase, red for 380V three-phase. The IP44 splash-proof rating makes these suitable for industrial, commercial, and temporary power applications. A coupler accepts a male CEE plug top and provides a female outlet on the cable end, typically used for cable extensions, distribution leads, and flexible power connections.

• Application: Cable extension leads, distribution boards, site power, industrial power connections
• Current ratings: 16A and 32A
• Configurations: 3 Pin (2P+E / 230V), 4 Pin (3P+E / 380V), 5 Pin (3P+N+E / 380V)
• Protection: IP44 splash-proof rated
• Colour coding: Blue = 230V single phase / Red = 380V three phase
• Type: Female coupler – mounts on cable end, accepts a male CEE plug top

Key Features

• IP44 rated for splash protection in industrial and semi-outdoor environments
• Available in 16A and 32A to suit different load and circuit requirements
• Three pin configurations: 3-pin (230V single phase), 4-pin (380V 3-phase), 5-pin (380V 3-phase + neutral)
• Standard IEC 60309 CEE format – compatible with matching CEE plug tops, sockets, and inlets
• Colour-coded per IEC standard for quick visual identification on site
• Suitable for cable extension leads, distribution sets, and flexible industrial power connections

Typical Applications

• Industrial cable extension leads
• Site power distribution sets and spider boxes
• Generator output cable connections
• Temporary power connections on construction sites
• Motor, pump, and machinery power leads
• Commercial and factory power distribution

Technical Specifications

Variant Reference

What's Included

• 1 x MCE IP44 CEE Coupler (as per selected specification)

Please note: Cable, plug tops, socket outlets, and installation accessories are not included. Matching CEE plug tops, socket outlets, and appliance inlets are available separately from Zisabo.

Installation & Compatibility Notes

• Select the correct current rating (16A or 32A) to match your plug top, socket, and circuit protection
• Select the correct pin configuration: 3P (230V single phase), 4P (380V 3-phase), or 5P (380V 3-phase + neutral)
• Ensure all components in the connection – plug top, coupler, socket – are the same current rating and pin configuration
• IP44 rating: suitable for splash-protected indoor and semi-outdoor environments – not suitable for full immersion
• Installation and termination should be carried out by a suitably qualified electrician
• If unsure of the correct specification for your application, contact Zisabo before ordering

Warranty & Support

This product is supplied with the applicable manufacturer or supplier warranty, subject to correct installation, correct application, and warranty terms. Zisabo supplies quality electrical products with practical support to help customers choose the correct item for their application. If you are unsure whether this product is suitable, contact us before ordering and our team will assist where possible.

Need help choosing? Contact Zisabo with your supply voltage, current rating, and pin configuration requirements and we will assist where possible.
