Multi Purpose Distribution Board, IP41, 6 Way

The MCE Electric GDB is a surface-mounted 6-way IP41 plastic distribution board, pre-fitted with a DTS-16C20A 7-day digital timer and a 12A mini contactor. It is ideally suited to any device that needs automatic on/off control — for example a geyser, pump, fan, irrigation system or lighting circuit — and suits homeowners, contractors and installers who want a ready-to-wire automatic control board rather than assembling one from separate parts.

• Application: Automatic on/off control of a geyser, pump, fan, irrigation, lighting or similar load
• Key specification: 6-way, IP41, pre-fitted with DTS-16C20A timer and 12A mini contactor
• Contactor voltage: Available for 230V or 400V systems — confirm which you need before ordering
• Manual override: Timer can be "by-passed" for manual intervention when needed

Key Features

• Pre-fitted with a DTS-16C20A 7-day digital timer, ready to programme the contactor's on/off schedule
• 12A mini contactor handles the switched load so the timer isn't switching the load directly
• Timer can be by-passed for manual control when automatic operation isn't wanted
• Surface-mounted 6-way IP41 plastic enclosure, ready to wire on site

Typical Applications

• Geyser automatic on/off scheduling
• Pump, fan or irrigation automatic control
• Lighting circuit scheduling
• Any single mains-powered device needing timed automatic control

Technical Specifications

What's Included

• 1 x GDB 6-way IP41 distribution board
• 1 x DTS-16C20A digital timer, pre-fitted
• 1 x 12A mini contactor, pre-fitted (confirm 230V or 400V when ordering)

Please note: The GDB does not include any protective device. An over-current/fault-current device suitable for protecting the switched equipment must be provided separately.

Installation & Compatibility Notes

• Confirm whether you need the 230V or 400V contactor version before ordering.
• You must fit a suitable over-current/fault-current protective device separately — this board does not include one.
• Installation should be carried out by a suitably qualified electrician.

Warranty & Support

This product is supplied with the applicable manufacturer or supplier warranty, subject to correct installation, correct application, and warranty terms.

Need help choosing? If you are unsure whether this board is correct for your application, contact Zisabo with your device details and supply voltage, and we will assist where possible.
