Pedrollo 4CP/4CPM Multi-Stage Centrifugal Pump – 80/100 Range

The Pedrollo 4CP/4CPM Multi-Stage Centrifugal Pump is a quiet, energy-efficient pump with a stainless steel impeller, recommended for pumping clean water in the domestic sector – particularly for water distribution with small or medium-sized autoclave/pressure tanks, and for irrigating vegetable gardens or orchards. Available in single-phase 230V (4CPm). The smaller 4CPm80 model is currently only available bundled with an Aquasystems pressure tank.

• Application: Domestic water distribution with pressure/autoclave tanks, garden and orchard irrigation.
• Motor options: Single-phase 230V (4CPm).
• Power: 0.55kW (0.75HP) to 0.75kW (1HP).
• Performance: Max head 50–52m, flow up to 100–130 L/min depending on model.
• Pump type: Multi-stage centrifugal with stainless steel (AISI304) impeller, cast iron body.
• Motor efficiency: IE2 single-phase motor class, per IEC 60034-30-1.

Key Features

• Multi-stage design: Delivers higher head than a single-stage centrifugal pump of comparable power, well suited to pressure-tank systems.
• Stainless steel impeller: AISI304 impeller and cover for durability and corrosion resistance.
• Integrated thermal protection: Single-phase motor has winding-integrated thermal motor protection built in.
• Quiet, energy-efficient operation: Designed for low-noise domestic installation.

Typical Applications

• Domestic water distribution with autoclave / pressure tank systems
• Vegetable garden and orchard irrigation
• Small-scale domestic pressure boosting

Technical Specifications

Connection size: 1" – confirm before ordering. Suction lift: up to 7m manometric suction head. Max working pressure: 6 bar.

Performance figures are read from the manufacturer's official Q/H curve at the flow points supplied. Tolerance of characteristic curves complies with EN ISO 9906 Grade 3B.

Configuration Options

The 4CPm100 is sold as "Pump Only". The 4CPm80 is currently only available bundled with an Aquasystems pressure tank (25L standard, or 50L horizontal tank) – ask Zisabo about standalone availability if you don't need the tank.

What's Included

• 1 x Pedrollo 4CPm multi-stage centrifugal pump (model as selected)
• Plus the tank listed in the Configuration option, where selected

Please note: Installation fittings, electrical protection, control boxes, cables, unions, brackets, or accessories are not included unless specifically listed above.

Installation & Compatibility Notes

• Confirm your required flow rate and head before ordering.
• These models run off a standard single-phase 230V household supply.
• Confirm connection size and pipe compatibility with Zisabo before ordering.
• Qualified installation is recommended, particularly where used with a pressure/autoclave tank system.

Warranty & Support

This product is supplied with the applicable manufacturer or supplier warranty, subject to correct installation, correct application, and warranty terms.

Zisabo supplies quality plumbing, pump, filtration and electrical products with practical support to help customers choose the correct item for their application. If you are unsure whether this product is suitable, contact us before ordering and our team will assist where possible.

Need help choosing? If you're unsure whether this pump suits your system, contact Zisabo with your required flow rate, head, and pipe size, and we'll help you select the correct pump.
