Pedrollo RX-VORTEX Submersible Drainage Pump – 230V

The Pedrollo RX-VORTEX Submersible Drainage Pump is an all-stainless-steel drainage pump for domestic, civil and industrial use, built for reliable continuous operation. Its vortex impeller passes suspended solids, and it can be submerged up to 10m deep – considerably deeper than a standard domestic sump pump. Includes a float switch and 5m power cable. Available in single-phase 230V.

• Application: Domestic, civil and industrial dirty-water drainage, deeper sumps and pits.
• Motor: Single-phase 230V.
• Power range: 0.37kW (0.50HP) to 1.1kW (1.5HP).
• Performance: Max head from 8m up to 12.8m, flow up to 190–380 L/min depending on model.
• Solids handling: Vortex impeller passes suspended solids up to Ø20mm (RXm2/20) or Ø40mm (RXm5/40).
• Construction: All AISI304 stainless steel wetted parts.
• Included: Float switch and 5m power cable with Schuko plug.

Key Features

• All-stainless-steel construction: Outer sleeve, suction filter, diffuser and impeller all in AISI304 stainless steel, for durability in industrial and civil use.
• Deeper submersion rating: Rated to 10m submersion depth, well beyond a typical domestic sump pump.
• Vortex impeller: Creates a whirlpool effect that lets solids pass through without clogging.
• Automatic float switch included: Starts and stops the pump automatically as water level changes.
• Double shaft seal: Seal with interposed oil chamber for added motor protection.

Typical Applications

• Deeper domestic, civil and industrial sump drainage
• Dirty water removal with larger suspended solids
• Industrial dewatering
• Civil drainage installations

Technical Specifications

Performance figures are read from the manufacturer's official Q/H curve at the flow points supplied. Tolerance of characteristic curves complies with EN ISO 9906 Grade 3B.

What's Included

• 1 x Pedrollo RX-VORTEX submersible drainage pump (model as selected)
• 1 x float switch
• 5m power cable with Schuko plug

Please note: This pump is for dirty/waste water, not clean drinking water distribution.

Installation & Compatibility Notes

• Confirm your required flow rate and head against the table above before ordering.
• RXm2/20 handles solids up to 20mm; RXm5/40 handles solids up to 40mm – check which suits your application.
• Runs off a standard single-phase 230V household supply.
• Qualified installation is recommended, particularly for deeper or permanent installations.

Warranty & Support

This product is supplied with the applicable manufacturer or supplier warranty, subject to correct installation, correct application, and warranty terms.

Zisabo supplies quality plumbing, pump, filtration and electrical products with practical support to help customers choose the correct item for their application. If you are unsure whether this product is suitable, contact us before ordering and our team will assist where possible.

Need help choosing? If you're unsure which model suits your system, contact Zisabo with your required flow rate, head, sump depth and expected solids size, and we'll help you select the correct pump.
